Websites, HTML, CSS
Understanding the basics of websites and HTML
Lecture Summary
- Static vs. Dynamic
- HTML
- CSS
- Bootstrap
Website Primer
Websites
Websites are simply servers that deliver files upon request.
. . .
They will always return HTML files
- HyperText Markup Language
. . .
The benefits of HTML
- Supported by every browser
- Very flexible formatting
- Light-weight (meaning websites load quickly)
Static vs. Dynamic Websites
HTML files are static.
. . .
This means that when you request a specific page from a server, you always get the same html file.
. . .
In contrast, some websites are dynamic.
- like amazon.com, netflix.com, nytimes.com etc.
. . .
When you visit Amazon, they dynamically build a webpage specific to you.
- Query their database for what products you like, what your recent purchases were, etc.
Client-side vs. Server-side Interactivity
A dynamic website will rebuild html files for each user using data on their servers.
. . .
You can, however, have some interactivity for static websites using JavaScript.
. . .
Javascript is another programming language that can run client-side (on your machine).
- Very good at editing html files
- allows for sites where you “click this button” to “show a figure”
- All of the interactive data visualizations you see from the NYTimes are written in JavaScript
HTML Files
We will focus on basic HTML files.
. . .
- static
- non-interactive
. . .
Really, an HTML file is just a messy document.
- similar to LaTeX, or markdown
HTML
Example HTML file
<!DOCTYPE html>
<html>
<head>
</head>
<body>
<p>Hello world!</p>
</body>
</html>HTML Document Structure
<!DOCTYPE html> tells the computer this is an html document
. . .
<html>
</html>These are opening and closing commands that wrap the entire html document.
. . .
Every HTML document has two key components:
- “head” for metadata and settings
- “body” for content
HTML Elements
Every HTML document is made up of a nested list of elements.
. . .
A basic element is <p></p> for paragraphs of text.
. . .
<p>defines the start of a text paragraph</p>defines the end
. . .
There are header elements as well:
<h1>Heading level 1</h1>
<h2>Heading level 2</h2>
<h3>Heading level 3</h3>
<h4>Heading level 4</h4>
<h5>Heading level 5</h5>
<h6>Heading level 6</h6>Example HTML with Headers
<!DOCTYPE html>
<html>
<head>
</head>
<body>
<h1>A Big Header</h1>
<p>Hello world!</p>
<h2>Another smaller header</h2>
<p>Some more text written in a paragraph block</p>
</body>
</html>Adding Links
An important part of any HTML document is linking to another webpage.
. . .
Links can be added with an <a> element.
<a href="https://www.wikipedia.org/">A link to Wikipedia!</a>Adding Links
An important part of any HTML document is linking to another webpage.
. . .
Links can be added with an <a> element.
<a href="https://www.wikipedia.org/">A link to Wikipedia!</a>Notice that this element/tag has an additional argument
href=is an attribute for the<a>elementdownload=is another posible<a>attribute
If download is set to a filename, then the linked document will be downloaded with that name instead of being opened.
Bold and Italics
We can set bold and italics text using the default <b> and <em> tags.
. . .
<!DOCTYPE html>
<html>
<head>
</head>
<body>
<p>Hello <b>world</b>!</p>
<h2>Another smaller header</h2>
<p>Some more <em>text</em> written in a paragraph block</p>
</body>
</html>Divs
<div> elements are html tags for divisions or sections.
- commonly used to group portions of a html document together.
<!DOCTYPE html>
<html>
<head>
</head>
<body>
<p>Hello <b>world</b>!</p>
<div>
<h2>Another smaller header</h2>
<p>Some more <em>text</em> written in a paragraph block</p>
</div>
</body>
</html>Divs
<div> elements are html tags for divisions or sections.
- commonly used to group portions of a html document together.
Setting Div Styles in HTML
We can use the <div> to set a style attribute for a group of html elements.
<!DOCTYPE html>
<html>
<head>
</head>
<body>
<p>Hello <b>world</b>!</p>
<div style="background-color:#FFF4A3;">
<h2>Another smaller header</h2>
<p>Some more <em>text</em> written in a paragraph block</p>
</div>
</body>
</html>Setting Div Styles in HTML
We can use the <div> to set a style attribute for a group of html elements.
Setting Styles in HTML
In fact, every HTML element has a style= attribute.
<!DOCTYPE html>
<html>
<head>
</head>
<body>
<p>Hello <b>world</b>!</p>
<div style="background-color:#FFF4A3;">
<h2>Another smaller header</h2>
<p>Some more <em style="background-color:#FFC0C7;">text</em> written in a paragraph block</p>
</div>
</body>
</html>Setting Styles in HTML
In fact, every HTML element has a style= attribute.
Inheritance
Notice that our “text” emphasis ends up red even though it is within the <div> tag.
. . .
This is because HTML elements inherit attributes and styles from parent elements
- but the lowest level element has priority
Inheritance Example
<!DOCTYPE html>
<html>
<head>
</head>
<body>
<p>Hello <b>world</b>!</p>
<div style="background-color:#FFF4A3;">
<h2>Another smaller header</h2>
<p>Some more <em style="background-color:#FFC0C7;">text</em> written in a paragraph block</p>
</div>
</body>
</html>Our “text” inherits from:
<html>then<body>then<div>then<p>then<em>
Setting Styles in the Header
Instead of setting styles for each tag, set them for all copies of an element.
<!DOCTYPE html>
<html>
<head>
<style>
p {background-color: #FFF4A3;}
em {color: blue;}
</style>
</head>
<body>
<p>Hello <b>world</b>!</p>
<div>
<h2>Another smaller header</h2>
<p>Some more <em>text</em>
written in a paragraph block</p>
</div>
</body>
</html>CSS
CSS
CSS stands for “Cascading Style Sheets”.
- Think of the inheritance chain for “cascading”
. . .
CSS controls the style of HTML elements.
. . .
It can be set in 3 ways:
- Inline with the
style=argument for a specific HTML element - Internal with the
<style></style>element in the<head>section - External with a
<link>to an external CSS file
External CSS File
styles.css
p {background-color: #FFF4A3;}
em {color: blue;}index.html
<!DOCTYPE html>
<html>
<head>
<link rel="stylesheet" href="styles.css">
</head>
<body>
<p>Hello <b>world</b>!</p>
<div>
<h2>Another smaller header</h2>
<p>Some more <em>text</em>
written in a paragraph block</p>
</div>
</body>
</html>Setting Classes
Now that we have seen CSS, it is useful to talk about one more HTML element attribute:
- classes
. . .
Any HTML element can be given a class.
. . .
You can specify styles for a specific class in your CSS.
Class Example
Class styles are set with .classname{}. Classes are set as attributes.
styles.css
.myclass {
color: blue;
font-size:30px;
}index.html
<!DOCTYPE html>
<html>
<head>
<link rel="stylesheet" href="styles.css">
</head>
<body>
<p>Hello <b>world</b>!</p>
<div class = "myclass">
<h2>Another smaller header</h2>
<p>Some more <em>text</em>
written in a paragraph block</p>
</div>
</body>
</html>Class Example Continued
Different elements can reference the same class.
styles.css
.myclass {
color: blue;
font-size:30px;
}index.html
<!DOCTYPE html>
<html>
<head>
<link rel="stylesheet" href="styles.css">
</head>
<body>
<p>Hello <b class="myclass">world</b>!</p>
<div class = "myclass">
<h2>Another smaller header</h2>
<p>Some more <em>text</em>
written in a paragraph block</p>
</div>
</body>
</html>Classes Summary
Classes are a powerful way to group different style formatting and apply them across elements.
You can define your own classes and the specific formating for those classes.
. . .
They can also be used by JavaScript for some interactive elements, but we won’t cover that.
Learning More HTML and CSS
I recommend checking out W3Schools’ HTML Tutorials for more information on HTML and CSS.
. . .
We have covered the very basics:
- HTML files are documents
- Consist of a
<head>and a<body> - The body has nested elements which have attributes
- Styles are set inline or in CSS files
- Elements inherit styles and attributes
Hosting Static Websites
Hosting Static Websites
There are many services for hosting static websites.
The one we will use is GitHub Pages.
GitHub Pages
Can be turned on for any repository.
You will need to tell it which “branch” has your HTML files
- probably “main”
And whether they are in the “root” folder or “docs/” subfolder
- default is “root” which is just the repository folder
- “docs/” is useful if you want to keep your website files separate
GitHub User Page
Each GitHub user can setup a home page for their GitHub account.
It is always called:
- “www.yourusername.github.io”
. . .
The URL for my account would be “https://www.matdehaven.github.io”
. . .
- But I have instead bought a custom domain https://matthewdehaven.com/
- and configured GitHub to use that domain instead
GitHub Project Pages
Every repository can have its own page.
. . .
By default, theses will all live at
- “www.yourusername.github.io/yourrepositoryname”
Website Home Pages
When you open a website location, your browser will by default open the file called
- “index.html”
. . .
So the most basic website you can create has only an “index.html” file, and maybe a “styles.css” file.
Bootstrap
Bootstrap 5
Bootstrap is a “framework” for HTML websites
. . .
- Includes HTML and CSS templates and pre-made elements
- And some JavaScript functions for interactivity
. . .
The goals of Bootstrap are
- fast and easy
- mobile-friendly
- responsive designs
Bootstrap Benefits
Bootstrap has…
- Nice default stylings
- And multiple “themes” to choose from
- dynamic resizing
- ex. on mobile, your website collapses menu buttons together
- fluid “containers” for your content
Bootstrap CDN
Bootstrap can be installed, or you can use the Content Delivery Network (CDN) to load it in the <head> of any HTML file.
. . .
<!DOCTYPE html>
<html>
<head>
<link href="https://cdn.jsdelivr.net/npm/bootstrap@5.3.3/dist/css/bootstrap.min.css" rel="stylesheet">
<script src="https://cdn.jsdelivr.net/npm/bootstrap@5.3.3/dist/js/bootstrap.bundle.min.js"></script>
</head>
<body>
</body>
</html>Bootstrap Features
- Buttons
- Navbars (menus at the top of the screen)
- Bootswatch Themes
- much more
Bootstrap Custom Image Borders
We can use Bootstrap to easily mask images. Notice the image is not quite square, so it is a tad squished.
<!DOCTYPE html>
<html>
<head>
<link href="https://cdn.jsdelivr.net/npm/bootstrap@5.3.3/dist/css/bootstrap.min.css" rel="stylesheet">
<script src="https://cdn.jsdelivr.net/npm/bootstrap@5.3.3/dist/js/bootstrap.bundle.min.js"></script>
</head>
<body>
<img src="figs/profile-pic.jpg">
<img src="figs/profile-pic.jpg" class="rounded">
<img src="figs/profile-pic.jpg" class="rounded-circle">
</body>
</html>![]()
Boostrap Default Theme
<!DOCTYPE html>
<html>
<head>
<link href="https://cdn.jsdelivr.net/npm/bootstrap@5.3.3/dist/css/bootstrap.min.css" rel="stylesheet">
<script src="https://cdn.jsdelivr.net/npm/bootstrap@5.3.3/dist/js/bootstrap.bundle.min.js"></script>
</head>
<body>
<div class="container-fluid p-5 bg-primary text-white text-center">
<h1>My First Bootstrap Page</h1>
<p>Lorem ipsum dolor sit amet</p>
</div>
<div class="container mt-5">
<div class="row">
<div class="col-sm-4">
<h3>Column 1</h3>
<p>Lorem ipsum dolor sit amet, consectetur adipisicing elit...</p>
<p>Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris...</p>
</div>
<div class="col-sm-4">
<h3>Column 2</h3>
<p>Lorem ipsum dolor sit amet, consectetur adipisicing elit...</p>
<p>Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris...</p>
</div>
<div class="col-sm-4">
<h3>Column 3</h3>
<p>Lorem ipsum dolor sit amet, consectetur adipisicing elit...</p>
<p>Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris...</p>
</div>
</div>
</div>
<div class="container-fluid text-center" style = "margin:30px">
<button type="button" class="btn btn-primary">Primary</button>
<button type="button" class="btn btn-secondary">Secondary</button>
<button type="button" class="btn btn-success">Success</button>
</div>
</body>
</html>Boostrap Default Theme
Bootswatch Theme: Darkly
<!DOCTYPE html>
<html>
<head>
<link href="https://cdn.jsdelivr.net/npm/bootswatch@4.5.2/dist/darkly/bootstrap.min.css" rel="stylesheet">
<script src="https://cdn.jsdelivr.net/npm/bootstrap@5.3.3/dist/js/bootstrap.bundle.min.js"></script>
</head>
<body>
<div class="container-fluid p-5 bg-primary text-white text-center">
<h1>My First Bootstrap Page</h1>
<p>Lorem ipsum dolor sit amet</p>
</div>
<div class="container mt-5">
<div class="row">
<div class="col-sm-4">
<h3>Column 1</h3>
<p>Lorem ipsum dolor sit amet, consectetur adipisicing elit...</p>
<p>Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris...</p>
</div>
<div class="col-sm-4">
<h3>Column 2</h3>
<p>Lorem ipsum dolor sit amet, consectetur adipisicing elit...</p>
<p>Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris...</p>
</div>
<div class="col-sm-4">
<h3>Column 3</h3>
<p>Lorem ipsum dolor sit amet, consectetur adipisicing elit...</p>
<p>Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris...</p>
</div>
</div>
</div>
<div class="container-fluid text-center" style = "margin:30px">
<button type="button" class="btn btn-primary">Primary</button>
<button type="button" class="btn btn-secondary">Secondary</button>
<button type="button" class="btn btn-success">Success</button>
</div>
</body>
</html>Bootswatch Theme: Darkly
Bootswatch Theme CDNs
You can view all the available Bootswatch themes available by CDN.
There are many options to choose from!
Bootstrap Summary
Bootstrap is a powerful tool for building websites.
- It is easy to use and mobile-friendly
- It has many pre-made elements and themes
- It can be loaded from a CDN
If you are interested in learning HTML and Bootstrap, I recommend the W3Schools’ Bootstrap Tutorial.
Other Website Templates:
- Single page websites, mobile-friendly, lots of options
Minimial Academic Bootstrap Website
- by me, one of the options to use for your next problem set
What About Google Sites?
There are various services for building websites that are “point-and-click”:
- Google Sites (free!), Squarespace, Wix, Wordpress
. . .
You lose some freedom but don’t need to know any programming.
But if you find yourself after this course intimidated by maintaining your own website, Google Sites is by far the easiest option.
Summary
Lecture Summary
- Static vs. Dynamic
- HTML
- CSS
- Bootstrap
Live Coding Example
Simplest HTML file website on GitHub Pages
Adding Bootstrap
Coding Exercise
In VS Code, add the Live Preview extension for previewing HTML files.
- Create a simple HTML file and preview it
- in VS Code
- in a browser
